PARTS LIST
LISTA DE PIEZAS
Speed Scrubt 2001 Battery (11–01)
45
LEVER GROUP
CONJUNTO DE PALANCAS
REF PART # DESCRIPTION QTY.
1 230661 PLATE, LOCK CONTROL HOUSING 2
2 602641 BRACKET, DRAIN HOSE HANGER 1
3 200816 DGRIP, HANDLE 2
4 230719 HANDLE, SOLUTION VALVE 1
5 230735 BUSHING, SPACER 2
6 140060 WASHER, .50 WAVE 2
7 140027 WASHER, 5/16 FLAT 4
8 140015 WASHER, 5/16 SPLITLOCK 4
9 140226 SCREW, 5/16–18X5/8 2
10 140510 NUT, 1/4–20 HEXJAM 1
11 140000 WASHER, 1/4 FLAT 4
12 140134 BUSHING 2
13 140208 SCREW, 1/4–20X1 2
14 230728 HANDLE, SQUEEGEE LIFT 1
15 140221 SCREW, 5/16–18X1–1/4 2
16 140016 WASHER, 1/4 LCK 2
17 140259 SCREW, 1/4–20X5/8 1
18 140510 NUT, 1/4–20 HEXJAM 1
19 140931 DCABLE, SQUEEGEE LIFT 1
20 230718 LEVER, SOLUTION VALVE 1
21 140951 SCREW, 10–24X7/16 2
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS
REF PART # DESCRIPTION QTY.
22 140031 WASHER, #10 EXT 2
23 230712 PLATE, SQUEEGEE LOCK 1
24 140616 PIN, ROLL 1
25 230657 ARM, VALVE 1
26 606238 HOSE, 3/8IDX5/8ODX18 1
27 607776 CLAMP, HOSE 2WIRE BLK 1
28 140011 WASHER, 3/16 FLAT 4
29 140552 NUT, 10–24 NYLOCK 2
30 210259 DVALVE, 3–WAY 1
31 140259 SCREW, 1/4–20X5/8 2
32 150406 FITTING, 1/4MX1/4F ELB 90 2
33 140016 WASHER, 1/4 LOCK 2
34 600750 BRACKET, VALVE 1
35 140895 SCREW, 10–24X3/4 2
36 150206 PLUG, HXHD 1/4” 1
37 605394 FITTING, HOSE BARB 1
38 150517 FITTING, 1/4MX1/2H BARB 1
39 606241 HOSE, 1/2ID X 6” 1
40 180629 FILTER, SOLUTION TANK 1
41 140501 NUT, 1/4–20 NYLOCK 1
42 607775 CLAMP, HOSE 2WIRE BLK 2
