PARTS LIST
LISTA DE PIEZAS
Speed Scrubt 2001 Battery (11–01)
47
NON-DRIVE MODEL WHEEL GROUP
CONJUNTO PARA LEVANTAR CEPILLO
REF PART # DESCRIPTION QTY.
1 230874 LEVER, BRUSH LIFT FOOT 1
2 200816 GRIP, HANDLE 1
3 102560 PAD, NON–SLIP 2
4 140509 NUT, 1/2–13 HEXJAM 4
5 140045 WASHER, .510X1.25X.06 FLAT 10
6 140139 BUSHING, BRUSH LIFT PEDAL 5
7 140024 WASHER, 1/2 LOCK 3
8 140236 SCREW, 1/2–13X1–1/4 HXHDCP 5
9 230870 WELDMENT, LIFT BRACKET 1
10 140516 NUT, 1/2–13 NYLOCK 2
11 230869 BRACKET, AXLE & SQ PIVOT MNT 2
12 140024 WASHER, 1/2 LOCK 4
13 140237 SCREW, 1/2–13X1 HXHDCP 6
14 140045 WASHER, .510X1.25X.06 FLAT 2
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS
REF PART # DESCRIPTION QTY.
15 140223 SCREW, 5/16–18X3/4 HXHDCP 2
16 140433 SPRING, EXTENSION 3” 2
17 140506 NUT, 5/16–18 HEX 2
18 140201 SCREW, 3/8–16X3/4 HXHDCP 2
19 140017 WASHER, 3/8 SPLITLOCK 2
20 140028 WASHER, 3/8 FLAT 2
21 607577 DWHEEL 8”X1.5” 2
22 230743 AXLE, 3/4 OD X 16–5/8 1
23 140234 SCREW, 1/2–13X2–1/2 HXHDCP 1
24 3148.816 WASHER, FLAT 1
25 140430 SPRING, HANDLE LOCK 1
26 140127 BEARING, THRUST 2
27 230871 BRACKET, MOTOR MOUNT 1
28 130040 WIRE TIE, NYLON 1
