PARTS LIST
LISTA DE PIEZAS
Speed Scrubt 2001 Battery (11–01)
49
BRUSH DRIVE GROUP
CONJUNTO IMPULSO DE CEPILLO
REF PART # DESCRIPTION QTY.
∇ 1 130491 DMOTOR, W/GEARBOX 24V IMP 1
Y 190970 DBRUSH, CARBON (SET OF 4) 4
Y 190741 DASM, BRUSH CARD 1
Y 630609 DGEAR BOX, IMPERIAL MOTOR 1
2 130192 TERMINAL ENDS 2
3 140431 SPRING, EXTENSION 5” 1
4 230871 BRACKET, MOTOR MOUNT 1
5 140823 SCREW, 10–24X5/8 TRSPHL 1
6 100091 BUMPER, RECESSED 1
7 140552 NUT, 10–24 NYLOCK 1
8 607775 CLAMP, HOSE 2WIRE BLK 1
9 609924 HOSE, 3/8IDX5/8ODX19” CLEAR 1
10 140017 WASHER, 3/8 SPLITLOCK 4
11 140202 SCREW, 3/8–16X1 HXHDCP 4
12 606335 PLATE, DRIVE MOLDED 1
13 606915 SCREW, HIGH–LOW 10–16X3/8 4
∇ ASSEMBLY / CONJUNTO
Y INCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS
REF PART # DESCRIPTION QTY.
14 230697 DSTOP, DRIVER RELEASE 1
15 230651 DCLAMP, BRUSH PLATE 1
16 140417 DCLIP, SPRING 1
17 25732 WASHER, FLAT 2
18 140015 WASHER, 5/16 SPLITLOCK 1
19 140219 SCREW, 5/16–18X1 HXHDCP 1
20 140234 SCREW, 1/2–13X2–1/2 1
21 3148.816 WASHER, FLAT 1
22 140430 SPRING 1
23 140127 BEARING, THURST 2
24 140509 NUT, 1/2–13 HXJM 3
25 140024 WASHER, 1/2 LOCK 2
26 140139 BUSHING, BRUSH LIFT PEDAL 2
27 140045 WASHER, .510X1.25X.06 FLAT 4
28 140236 SCREW, 1/2–13X1–1/4 2
