PARTS LIST
LISTA DE PIEZAS
Speed Scrubt 2001 Battery (11–01)
53
CURVED SQUEEGEE ASSEMBLY
CONJUNTO PALETA ENCORUADO
REF PART # DESCRIPTION QTY.
1 230731 PIVOT, SQUEEGEE MOUNT 1
2 140045 WASHER, FLAT 4
3 140024 WASHER, LOCK 2
4 140237 SCREW, 1/2–13X1 2
5 140931 DCABLE, SQUEEGEE 1
6 140139 BUSHING 2
7 140524 NUT, LOCK 1/4 2
8 140433 SPRING 2
9 160617 DHOSE, 1 1/2X24” W/CUFFS 1
10 230730.BK BRACKET, SQUEEGEE MOUNT 1
∇ 603261 DASM., SQUEEGEE 1
Y 11 605361 DKNOB, BLACK 2
Y 12 603260 DGASKET, SQUEEGEE 1
Y 13 140226 SCREW, 5/16–18X 5/8 2
Y 14 140015 WASHER, LOCK 2
∇ ASSEMBLY
Y INCLUDED IN ASSEMBLY
D RECOMMENDED STOCK ITEMS
REF PART # DESCRIPTION QTY.
Y 15 700844 DASM, SQUEEGEE ROLLER 2
Y 16 140799 SCREW, 5/16–18 X 1 1/2 2
Y 17 630450 DWHEEL, W/BUSHINGS 2
Y 18 602959 WELDMENT, SQUEEGEE 1
Y 19 605975 SCREW, 10–24X1/2 SEMS 18
Y 20 602964 DPLATE, SQUEEGEE 2
Y 21 603659 DBLADE, URETHANE (STANDARD) 2
Y 22 140221 SCREW, 5/16–18X1 1/4 2
∇ 611453 DKIT, SQUEEGEE LINATEX
(OPTIONAL)
1
Y 607465 DBLADE, LINATEX REAR ONLY
(OPTIONAL)
1
Y 611449 DBLADE, LINATEX FRONT ONLY
(OPTIONAL)
1
606676 DBLADE, GUM RUBBER REAR
ONLY (OPTIONAL)
1
