26
Table 3. Light indicators during normal operation
* Depends on whether the Nokia 32 terminal is in the trunk or the extension mode.
Green blink - - Unacceptable: 105...100 dBm
Green - - Weak: 100...95 dBm
Green Green blink - Weak: 95...90 dBm
Green Green - Moderate: 90...85 dBm
Green Green Green blink Moderate: 85...80 dBm
Green Green Green Good: -> 80 dBm
LED 1LED 2LED 3Description
- Green Green In service, trunk mode
Green - Green In service, extension mode
* * Green blink Call in progress/incoming call
* * Green/red
blink
Message/voice mail received
* * Red blink Message storage full
- Green blink Green In Permanent fax mode/
waiting for a fax call
LED 1 LED 2 LED 3 Field strength
