Light indicators
25
Copyright
© 2003 Nokia. All rights reserved.
6. Light indicators
The Nokia 32 terminal has three red and green light
indicators that indicate the status of both the GSM
terminal and the PBX application module. See the
tables below.
Table 1. Start-up light indicators
Table 2. Field strength light indicators
LED 1LED 2LED 3Description
- - - Power is off
Green scan Green scan Green scan Power is on. The Nokia 32
terminal is attempting to
connect to the network
- Red blink - Enter the PIN code
- Red blink Red blink Enter the PUK code
LED 1 LED 2 LED 3 Field strength
Red blink - - Unacceptable: <- 105 dBm
