Copyright © 2003 Nokia. All rights reserved.
42
Extension interface
Power supply ACW-5
Antenna
The Nokia 32 terminal has an integrated antenna. The use of an external antenna
is supported with the XRM-1 antenna adapter.
RS-232
A D9 female connector for standard level RS-232 is available. It supports AT
commands (ITU-T V. 25ter, ETS GSM 07.07, ETS GSM 07.05).
Electromagnetic compatibility (Europe)
The GSM terminal is tested for electromagnetic compatibility (EMC) according to
the ETS 300 342-1/13/standards. The application module fullfils the ITU-T
Off-hook AC impedance 600 Ohm
Loop DC current 15-120 mA
Voltage 13.5 V
DC current 750 mA
Operating range 90-264 Vac
Frequency range 47-63 Hz
Weight 70 g + cables
Volume <110 cm3
Eppu_en1.fm Page 42 Thursday, January 8, 2004 3:48 PM
