Pay-As-You-Grow Licensing
20
PAY-AS-YOU-GROW FP4 HARDWARE LICENSING
REFERENCE GUIDE
3HE 15453 AAAA TQZZA 01 Issue: 02
Figure 8 is an example of a 7750 SR-14s containing 3HE13740AA in card slot 1, mda
slot 1, which has been properly configured as cr1600g to match the level of the
installed part.
3HE12388BA XMA - SR-s 2.4T 24pt QSFP28 ER er2400g 7750 SR-s XMA (Expandable
Media Adapter) 2.4Tb 24-port
QSFP28, ER (Edge Router)
feature set
3HE12388CA XMA - SR-s 2.4T 24pt QSFP28 HE he2400g 7750 SR-s XMA (Expandable
Media Adapter) 2.4Tb 24-port
QSFP28, HE (High-Scale Edge)
feature s
3HE11307AA XMA - SR-s 2.4T 36pt QSFP28 CR to 3.6T cr2400g+ 7750 SR-s XMA (Expandable
Media Adapter) 2.4Tb 36-port
QSFP28, CR (Core Router)
Aggregation mode to 3.6Tb feature
set
3HE11307BA XMA - SR-s 2.4T 36pt QSFP28 ER to 3.6T er2400g+ 7750 SR-s XMA (Expandable
Media Adapter) 2.4Tb 36-port
QSFP28, ER (Edge Router)
Aggregation mode to 3.6Tb feature
set
3HE11307CA XMA - SR-s 2.4T 36pt QSFP28 HE to 3.6T he2400g+ 7750 SR-s XMA (Expandable
Media Adapter) 2.4Tb 36-port
QSFP28, HE (High-Scale Edge)
Aggregation mode to 3.6Tb feature
set
Table 5 Configuration Example for a 7750 SR-14s 2-Complex XMA (Continued)
Part Number Description Card
Level
Name
Card Level Description
