RADIUS ATTRIBUTES REFERENCE GUIDE
RELEASE 14.0.R4
RADIUS Attributes Reference
Issue: 01 3HE 10793 AAAB TQZZA 01 239
6 Service-Type The type of service the PPPoE user has requested, or the type of
service to be provided for the PPPoE user. Optional in RADIUS-Accept
and CoA. Treated as a session setup failure if different from Framed-
User.
31 Calling-Station-Id Includes the hostname and sap-id.
Send when calling-station-id is included in configure aaa l2tp-
accounting-policy policy-name include-radius-attribute calling-
station-id
32 NAS-Identifier A string (configure system name system-name) identifying the NAS
originating the Authentication or Accounting requests and sent when
nas-identifier is included for the corresponding application: configure
aaa l2tp-accounting-policy (L2TP accounting).
41 Acct-Delay-Time Indicates how many seconds the client has been trying to send this
accounting record for. This attribute is included with value 0 in all initial
accounting messages. Attribute is omitted in accounting via configure
subscriber-mgmt radius-accounting-policy name include-radius-
attribute no acct-delay-time.
42 Acct-Input-Octets Tunnel-link and Tunnel level accounting uses the ESM accounting
statistics. For Tunnel Link Stop it reports the input bytes for this user
over the course of this service being provided. For Tunnel Stop this
attribute represent an aggregate of input bytes of all sessions that
belong(ed) to this tunnel over the course of this service being provided.
Attribute [52] Acct-Output-Gigawords indicates how many times (if
greater than zero) the [42] Acct-Input-Octets counter has wrapped
around 2^32 in the course of delivering this service.
43 Acct-Output-Octets Tunnel-link and Tunnel level accounting uses the ESM accounting
statistics. For Tunnel Link Stop it reports the output bytes for this user
over the course of this service being provided. For Tunnel Stop this
attribute represent an aggregate of output bytes of all sessions that
belong(ed) to this tunnel over the course of this service being provided.
Attribute [53] Acct-Output-Gigawords indicates how many times (if
bigger than zero) the [43] Acct-Output-Octets counter has wrapped
around 2^32 in the course of delivering this service.
44 Acct-Session-Id Is a unique generated number and maps for the Tunnel-link stop to the
accounting-session-id of the PPPoE session (show service id service
id ppp session detail). For Tunnel-stop accounting it is longer and a
concatenation of start-time and connection-id with delimiter. The start-
time equals to the node uptime reported in Timeticks (nd:hh:mm:ss:ts)
and value/6000 gives the uptime in minutes. The connection-id equals
{tunnel-id * 65536} and the tunnel-id maps to L2TP AVP 9 Assigned
Tunnel Id.
Table 72 L2TP Tunnel Accounting (Description) (Continued)
Attribute ID Attribute Name Description
