Nokia Flexi Multiradio BTS User Manual

Figure7
Isometricviewof6x40WRFModule
5.2 Overview of Flexi Multiradio BTS RRH
TheFlexiMultiradioRadioRemoteRadioHead(RRH),isaonesector,multi-standard
radiotransceivermodule.Eachbranchconsistsofatransmitterandreceiverchain.Itis
intendedforoutdoormountingandoptimizedforfeederlessapplications.
g
Inthisdocumentthefollowingnamingconventionhasbeenadopted:
Table4
RRHnamingconvention
RF Module variant RF Module variant list
2x40WRRH
FHCA
FHDA
FHEA
FRGQ
FRHB
FRMB
2x60WRRH
FHEB
FHDB
FRGY
4x30WRRH
FRIG
FRHD
FRHE
g
Thefollowing2x60WRRHvariantsdonotsupportthelegacyMHA/TMA:
FHDB,FHEB.DualMHAwhichoperatesinASIGmode.CurrentModeisnot
supported.
Overview FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
18 DN0951745 Issue:05
 
