Figure23
2x60WRRHfrontpanelconnectors
OPT1
LED
EAC
ANT1
DC Input
GND
RET
OPT2
ANT2
Figure24
4x30WRRHfrontpanelconnectors
7.5 RRH front panel description
Theconnectorsonthefrontpanelofthe,theirtype,andpurposearelistedintheTable
8:RRHexternalinterfaces.
Table8
RRHexternalinterfaces
Variant PWR IN ANT Rx EXT RET EAC OPT LMP
RRH2x40W
730MHz
3-polescrew
terminal
2x7/16
female
2xQMA,
female
8-pin
circular
D-sub
MDR14
SFP 2x15pin
header
FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
RFModuleandRRHinterfaces
Issue:05 DN0951745 37
 
