Nokia Flexi Multiradio BTS - Front Panel Views of RRH

7.4 Front panel views of RRH
Figure22
2x40WRRHfrontpanelconnectors
ANT1
ANT2
RET
OPT1
OPT2
MOD
(LED Module status)
DC INPUT
EAC
Tx
(LED Tx status)
Grounding
points
RFModuleandRRHinterfaces FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
