7 RF Module and RRH interfaces
7.1 Front panel views of RF Module
Figure16
FXDA,FXEA,andFXDJfrontpanelview
RxO 1
Grounding
points
LED Module
status
LED
Fan/TX Off
status
PWR IN
ANT 6
RX
ANT 5
TX/RX
ANT 4
RX
ANT 3
TX/RX
ANT 2
RX
ANT 1
TX/RX
EAC
OPT 1
OPT 2
OPT 3
RxO 5
RxO 3
g
SomeoldermodulesuseANT1RxOut,ANT3RxOut,ANT5RxOutinsteadof
RxO1,RxO3,andRxO5.
Figure17
FXFxandFXCAfrontpanelview
RxO 2
Grounding
points
LED Module
status
LED
Fan/TX Off
status
PWR IN
ANT 6
RX
ANT 4
RX
ANT 3
TX/RX
ANT 2
RX
ANT 1
TX/RX
EAC
OPT 1
OPT 2
OPT 3
RxO 6 RxO 4
TX/RX
RxO 1RxO 3RxO 5
RET (FXFB only)
RFModuleandRRHinterfaces FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
28 DN0951745 Issue:05
 
