Nokia Flexi Multiradio BTS User Manual

Table14
RFModulepowerconsumption(Cont.)
RF Module variant Maximum
number of TX
RF output
power per
sector
[W]
Est. power consumption [W] at
48 VDC input in 23 °C
50% RF load 100% RF load
20 353 428
RFM3x60W
2100MHz
FRGP_A
FRGP_B
3
60 584 804
40 490 647
20 393 476
RFM3x80W
2100MHz
FRGT/S
3
80 560 884
60 522 729
40 407 544
20 316 386
RFM3x60W
2600MHz
FRHA
3
60 806 1130
40 622 825
20 462 580
RFM6x40W
2600MHz
FRHC
6
40+40 808 1101
20+20 548 698
RFM6x40W
2600MHz
FRHF
6
40+40 828 1148
20+20 574 748
8.2 RRH Module power requirements
RRH Module input voltage range
Table15
RRHModuleinputvoltagerange
Property Value
Nominalsupplyvoltage -48.0VDC
FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
Powerrequirementsandoutputpower
Issue:05 DN0951745 49
 
