Nokia Flexi Multiradio BTS - RF Module Isometric View

5.1.2 RF Module isometric view
Figure2
IsometricviewofRFModuleFXDx,FXEx,FXFx,FXCx
Figure3
IsometricviewofRFModuleFXCA
g
TheFXFxandFXCxvariantshaveextraQMAconnectorsforE911positioning
systems.
