Nokia Flexi Multiradio BTS User Manual

Table2
RFModulefrequencyrangeandbandwidth(Cont.)
RF Module
variant
TX
frequency
range
[MHz]
RX
frequency
range
[MHz]
DL
instantane
ous
bandwidth
[MHz]
UL instantaneous
bandwidth
[MHz]
DL filter
bandwidth
[MHz]
UL filter
bandwidth
[MHz]
RFM3x80W
2100MHz
FRGS
2)
1920-1980 2110-2170 40 40 40 40
RFM6x40W
2600MHz
FRHC
2620-2675 2500-2555 40 40 55 55
RFM6x40W
2600MHz
FRHF
2640-2690 2520-2570 40 40 50 50
RFM3x60W
2600MHz
FRHA
2620-2690 2500-2570 20 20 70 70
Table3
RFModuleFRGTandFRGSoutputpowerinRU40
RF Module variant DL bandwidth
[MHz]
Output power [W]
FRGT,FRGS 0-20 80
FRGS 20-40
70
3)
FRGT 20-45
70
3)
FRGT 45-60 60

3)
BTScanbecommissionedas80W(forexample4x20Wperpipe)andRFMinternalpowercontrollimits
thetotalpowerto70Wwhenneeded.
FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
Overview
Issue:05 DN0951745 15
 
