Nokia Flexi Multiradio BTS User Manual

Table7
RFModuleantennalinedevicesupport(Cont.)
ALD support via antenna ports RET port
AISG Leg. CWA Voltage Power/p
ort
RET port Power
FXCA
RFM3x80W
850MHz
FXCB
2.0
Main
only
No Yes Main=13V/1.3Aor
24V/30W
Div=13V/1A

Yes 24V/
30W
RFM3x60W
900MHz
FXDA
2.0
Main
only
Yes Yes Main=12V/1Aor
24V/30W
Div=12V/1A

No
RFM3x60W
900MHz
FXDJ
2.0
Main
only
Yes Yes Main=12V/1Aor
24V/30W
Div=12V/1A

No
RFM3x80W
900MHz
FXDB
2.0
Main
only
No Yes Main=13V/1.3Aor
24V/30W
Div=13V/1A

Yes 24V/
30W
RFM3x60W
1800MHz
FXEA
2.0
Main
only
Yes Yes Main=13V/1.3Aor
24V/30W
Div=13V/1A

No
RFM3x80W
1800MHz
FXEB
2.0
Main
only
No Yes Main=13V/1.3Aor
24V/30W
Div=13V/1A

Yes 24V/
30W
RFM3x80W
1800MHz
FXFC
2.0
Main
only
No Yes Main=13V/1.3Aor
24V/30W
Div=13V/1A

Yes 24V/
30W
RFM3x60W
1900MHz
FXFB
2.0
Main
only
No Yes Main=13V/1.3Aor
24V/30W
Div=13V/1A

Yes 24V/
30W
RFM3x60W
2100MHz
FRGP_A
2.0
Main
only

Yes Yes Main
24V/12V
Div12V

30W No
RFModuleandRRHinterfaces FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
34 DN0951745 Issue:05
 
