Nokia Flexi Multiradio BTS User Manual

Table14
RFModulepowerconsumption
RF Module variant Maximum
number of TX
RF output
power per
sector
[W]
Est. power consumption [W] at
48 VDC input in 23 °C
50% RF load 100% RF load
RFM6x40W
700MHz
FRPA
6 40+40
778 1038
20+20
514 632
RFM6x40W
700MHz
FRPB
6
40+40 778 1033
20+20 517 637
RFM3x60W
800MHz
FRMA
3
60 669 943
40 510 673
20 374 450
RFM3x60W
800MHz
FRMD
3
60 621 826
40 486 616
20 369 435
RFM6x40W
800MHz
FRMC
6
40+40 784 1071
20+20 510 657
RFM3x60W
850MHz
FXCA
3
60 545 794
40 468 644
20 393 494
RFM3x80W
850MHz
FXCB
3
80 671 935
60 594 810
40 444 581
20 351 428
RFM3x60W
900MHz
3 60 700 932
40 533 672
FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
Powerrequirementsandoutputpower
Issue:05 DN0951745 47
 
