Programming is completed when
Flashing Completed
message is displayed.
The product type designator and MCU SW version are displayed in the status bar.
vi Close the
SW Update
window and then choose File→Close Product .
2. Create a
Request
file.
For this procedure, you must supply +12 V to CU-4 from an external power supply.
i To connect the phone with
Phoenix
, choose File→Scan Product .
ii Choose Tools→Certificate Restore .
iii To choose a location for the request file, click Browse.
RM-91; RM-92
BB Troubleshooting and Manual Tuning Guide Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 6 –41
Copyright © 2006 Nokia. All rights reserved.
