Nokia N80 - Back Camera Electrical Characteristics; Display Connector and Interface Connections

Description Parameter Min Typ Max Unit Notes
High-level
output
voltage
V
OH
1.62 V
DDS
1.98 V Column
Low-level
output
voltage
V
OL
0 0.45 V Column
(VDDS = 1.8V)
Display connector and interface connections
Table 23 S60 connector pin assignment from main UI board
Pin Signal I/O Engine connection Notes
1 GND X GND
2 GND X GND
3 COL0 -> APE KBC_0
4 ROW6 -> APE KBR_6
5 COL1 -> APE KBC_0
6 ROW5 -> APE KBR_5
7 COL2 -> APE KBC_2
8 GND X GND
9 GND X GND
10 ROW1 -> APE KBR_1
11 COL3 -> APE KBC_3
12 ROW0 -> APE KBR_0
13 LEDOUT <- N2300 LED driving
voltage
14 SETCURRK
LED
-> N2300 LED return
current.
15 GND X GND
16 GND X GND
Back camera electrical characteristics
Table 24 Camera CCP IF electrical characteristics
Description Parameter Min Typ Max Unit Notes
Common mode voltage VCMF 0.8 0.9 1 V -1
Differential voltage swing VOD 100 150 250 mV -2
Operating frequency fCLK 1 175 MHz SW controls
frequency
RM-91; RM-92
