Item Side Grid ref. Type Description and value
C2312 Bottom G 8 0402C
CHIPCAP X5R 1U K
6V3 0402 1u0 6.3V
C2314 Bottom G 10 0805C
CHIPCAP X5R 4U7
M 25V 0805 4u7 25V
C2316 Bottom G 9 0402C
CHIPCAP X5R 1U5 K
4V 0402 1u5 4V
C2317 Bottom G 9 0402C
CHIPCAP X5R 1U5 K
4V 0402 1u5 4V
C2320 Bottom H 10 0603C
CHIPCAP X5R 10UF
6V3 0603 10u 4V
C2700 Bottom I 3 0402C_H0.6
CHIPCAP X5R 100N
M 16V 0402 100n 16V
C2800 Top I 14 0402C_H0.6
CHIPCAP X5R 100N
M 16V 0402 100n 16V
C2801 Top F 15 0402C_H0.6
CHIPCAP X5R 100N
M 16V 0402 100n 16V
C2802 Top G 12 0402C_H0.6
CHIPCAP X5R 100N
M 16V 0402 100n 16V
C2803 Top F 14 0402C_H0.6
CHIPCAP X5R 100N
M 16V 0402 100n 16V
C2804 Top I 13 0402C_H0.6
CHIPCAP X5R 100N
M 16V 0402 100n 16V
C2805 Top F 14 0402C_H0.6
CHIPCAP X5R 100N
M 16V 0402 100n 16V
C2806 Top F 15 0402C_H0.6
CHIPCAP X5R 100N
M 16V 0402 100n 16V
C2807 Top I 14 0402C Chipcap 5% NP0 12p 50V
C2809 Top I 12 0402C
Chipcap X7R 10%
50V 0402 1n0 50V
C3502 Bottom G 10 0405_GNM23
CHIP ARRAY X5R
2X1U K 6V3 MA
0405 2x1u 6.3V
C3503 Bottom G 8 0405_GNM23
CHIP ARRAY X5R
2X1U K 6V3 MA
0405 2x1u 6.3V
C4000 Top F 10 0402C Chipcap 5% NP0 15p 50V
C4001 Top F 10 0402C Chipcap 5% NP0 100p 50V
C4002 Top F 10 0402C
CHIPCAP X5R 1U K
6V3 0402 1u0 6.3V
C4003 Top F 10 0402C
CHIPCAP X5R 1U K
6V3 0402 1u0 6.3V
