Nokia N80 - Page 77

Item Side Grid ref. Type Description and value
R3507 Bottom F 9 0402_VAR
CHIP
VARISTOR
VWM14V
VC50V
0402 14V/50V ~
R5508 Top H 7 0402R
Chipres
0W06
jumper
0402 0R ~
R6522 Bottom D 16 0402R
Chipres
0W06
jumper
0402 0R ~
X2000 Bottom C 1
CON_JACK_
HR33NK_2
DJA_2S
CONN DC-
JACK 2.0MM
3POL SPR
90DEG ~ ~
RM-91; RM-92
