3.
Make the following settings:
Setting
Value
Active Unit
Tx
Rx/Tx Channel
37
Band
GSM 900
AFC
0
Operation Mode
Burst
Edge
Off
Tx Data Type
Random
Tx PA Mode
High
Tx Power Level
5
4.
Check the basic TX parameters, using a communication analyser (e.g. CMU200).
•
Power
•
Phase error
•
Modulation
•
Switching spectrum
RM-598; RM-604
RF Troubleshooting
Issue 1
COMPANY CONFIDENTIAL
Page 4 –17
Copyright © 2009 Nokia. All rights reserved.
