Introduction
Phone description
RAP3GS is the main digital baseband ASIC in the device. It contains functionality for both WCDMA and GSM
EDGE. The cellular baseband is constructed around Radio Application Processor (RAP3GS2v4) and mixed signal
ASIC GAZOO/PEARL. RAP3GS2v4 is used as a single chip solution, which means that all UI components are
connected to RAP3GS2v4.
N2200 is the main audio and energy management controller for the phone. The mixed-signal functionality
is in one mixed-signal ASIC. In the cellular baseband there are two alternative pin compatible mixed signal
ASICs; GAZOO and PEARL. N2200 includes blocks for charger control, SMPS power supplies for VCORE, VIO and
LEDs, linear regulators for RF and BB supplies, level shifter functions, A/D converters, audio and RTC.
Bluetooth and FM radio are physically integrated in one single ASIC.
Key components
Function Description Item ref
Main board 2XGA
UI flex 2XHA
Energy management ASIC GAZOO/PEARL N2200
RF ASIC Vapaus N7500
Processor RAP3GS2v4 D2800
PA GSM Front end module (FEM), quad band N7520
PA WCDMA Triple band PA N7540
Oscillators VCTCXO G7500
Memory 1 Gbit M3/ DDR SDRAM 512 Mbit combo (stacked with RAP) D3000
FM radio BTHFMRDS3.0 module N6000
Bluetooth BTHFMRDS3.0 module N6000
Slide switch Hall IC switch/position sensor N2460
Battery BL-4CT
Battery connector Tabby blade interface X2080
UI flex connector Coax 40-pin connector X1000
MicroUSB connector For data and charging X2002
MicroSD connector X3200
SIM connector X2700
Microphone B2104
IHF speaker
Earpiece On UI flex B1000
RM-598; RM-604
System Module
Issue 1 COMPANY CONFIDENTIAL Page 5 –5
Copyright © 2009 Nokia. All rights reserved.
