Page9
Visitwww.solutions.norac.caformoresystem
installationandtroubleshootinginfo.
5.2. ValveBlockMounting
1. AsuitablemountinglocationforthevalveblockisillustratedinFigure5andFigure6.
Note: Thevalveblockcannotbemountedonthetopofthebo om.Ifthevalveblockismountedontop,it
willbehitwhentheboomrolls.
2. Mountthemanifoldtothebracket(B15)usingthehardwaresupplied.
3. Attachthemountingbracketandvalvetothesprayerusingtheremininghardware.
4. Cutoffexcessboltorstudlengthifnecessary.

Figure5:ValveBlockMountingonMachinesPriorto2022

Figure6:ValveBlockMountingonMachines2022+
