6.4. WingSensorInstallation
Ifinstallingathreesensorsystem,refertoSection6.4.1.
Ifinstallingafivesensorsystem(severeterrainoption),refertoSection6.4.2.
6.4.1. InstallationofaThreeSensorSystem
WheninstallingtheMAXSensors™(E07),startwiththesmallestserialnumberontheleft‐handside andproceed
tothelargestserialnumberontheright‐handside.Eachsensorhasaserialnumberstampedonthesensor
housing.
ApplyalightcoatingofthesuppliedPermatexAnti‐seizegreasetoallthreadedpartsuponinstallation.

Figure15:SensorSerialNumberArrangement
1. Thesensorbracketshouldbeorientedforward(aheadoftheboom).
2. Typically,thebestmountinglocationforthewingsensorbracketswillbeneartheendoftheboomtips,
approximatelytwofeet(0.6m)fromtheend(Figure17andFigure18).
3. Mountthe MAXsensors(E07)into thesensorbrackets.Runthesensorcablethroughholeinthebackof
thebracket.Ensurethecableisclearofmovingpartsandwillnotbedamagedduringfolding.
