7  ElectronicInstallation
7.1. HCM1Installation
1. Verifythevalvecoilconnectorsareorientedvertically(Figure25).Looseningthelargeplasticnutwillallow
theconnectortoberotated.

Figure25:AlignCoils

Figure26:HCM1Connections

Figure27:HCM1Label
2. Laythelongerbranchofthevalvecables(C10)acrossthecoilswithone4‐pinconnectoroneachside.Do
notconnectthecablesatthistime.
OutputNumber NormalFunction
1,2 LeftUpandDown
3,4 RightUpandDown
5,6 MainUpandDown
7,8 RollCWandCCW
