6  UltrasonicSens orInstallation
6.1. UltrasonicSensorMountingGuidelines
Thefollowingguidelineswillensureoptimalsensorperformanceandpreventsensormeasurement.
1. Initslowestposition,thesensormustbe9inches(230mm)ormorefromtheground.
2. Ensurethattherearenoobstructionswithina12inch(300mm)diametercircleprojecteddirectlybelow
thecenterofthesensor.
3. Thesensorshouldbeapproximatelyverticalatnormaloperatingheights.

Figure10:SensorMountingGuidelines

Figure11:BracketMountingGuidelines
6.2. LowProfileBracketMountingGuidelines
1. Minimizethe distancebetweenthe boltsto prevent bendingthe bracket andpreventthe bracketfrom
looseningovertime.
2. Ensurethebracketismountedtightagainstthebottomoftheboom,minimizingthedistancebetweenthe
boomstructureandtheangledflange.

Aproblemcanariseifasensorisnotmountedcorrectly.Thismayonlybecomeapparentoncethecontrol
systemisswitchedfromsoiltocrop mode.
Becarefulthatthesensorbracketdoesnotcollidewithanyotherpartoftheboomwhentheboomisfolded
totransportposition.Ifpossible,mountthesensorbracketswhiletheboomsarefoldedtoensuretheywill
notcauseinterference.
