6.3. RainflapInstallation

Rainflapsareonlyinstalledinthewingsensorbrackets.
1. Insertonesideoftherainflaprodintothepre‐benthingetabonthesensorbracket.(Figure12)

Figure12:RainflapRodinPre‐BentHingeTab
2. Aligntheothersideoftherainflaprodwiththeunbenthingetab.(Figure13)

Figure13:AlignRainflapRod
3. Bendthehingetabinwardovertherainflaproduntilthehingetabfitssecurelyinthedetentgrooveon
thebacksideofthesensorbracket.(Figure14)

Figure14:BendRainflapHingeTab
4. Ensuretherainflapactuatessmoothlywhenthebracketisturnedupsidedownandreturnstotheopen
positionwhenthesensorbracketisreturnedtoitsoperatingposition(sensorpointingdownwardstoward
theground).
