Norac Apache UC7 - Main Lift Sensor Installation

WWW.NORAC.CA
PRECISIONDEFINED


Page18
Visitwww.solutions.norac.caformoresystem
installationandtroubleshootinginfo.
6.5. MainLiftSensorInstallation
1. Themainliftmountingbracket(B21)isthebracketwiththelongermountingflange.
2. Thereareavarietyofwaystomountthemainliftbracketonmostsprayers.Thebracketshouldposition
thesensorapproximatelyinthecenterofthesprayer,forwardoftheboom.
  
Figure22:BracketMountingExample
3. MounttheMAXsensortothemainlift  bracket.Run the sensorcablethroughtheholeandbehindthe
bracket.

Figure23:MainLiftBracketMountingonMachinesPriorto
2022

Figure24:MainLiftBracketMountingonMachines2022+


Ensurethebracketdoesnotcollidewithanyotherpartofthesprayerthroughoutthefullrangeofmainlift
motion.
Front
