Figure20:ApacheSpacerPlacementonInnerWingBrackets(SteelBoom)
5. Pommierboom:MountthebracketasshowninFigure21.Thespacersarenotneededforthistypeof
install.

Figure21:InnerWingBracketonPommierBoom
6. Mountthe MAXsensors(E07)into thesensorbrackets.Runthesensorcablethroughholeinthebackof
thebracket.Ensurethecableisclearofmovingpartsandwillnotbedamagedduringfolding.
7. ConnectcablesC05tothe8‐waycouplerandroutealongtheboomtotheoutersensorbracket.
8. Attheoutersensorbrackets,attacha3‐waycoupler(E10)tothesprayerboom.ConnectcablesC05and
thesensorcabletothe3‐waycoupler.
9. ConnectcablesC06tothe3‐waycoupler(E10)androutealongtheboomtotheinnerwingsensors.
10. Attheinnersensorbrackets,attacha2‐waycouplerwithterminator(E20)tothesprayerboom.The2‐
waycouplerwithterminatoristhewhite2‐waycoupler.Plugthe sensorandtheCANbuscableintothe
terminator.

 
Spacer
(B12)
