4  Pre‐InstallationChecklist
Thepre‐installchecklistisnecessarytochecktheexistingsprayerfunctionalitybeforetheinstallation.
1. Unfoldthesprayeroveraflat,unobstructedarea(i.e.nopowerlines…etc.).
2. Ensureallboom‐foldoperationsarefunctional(placeacheckmarkinboxesbelow).
3. Bringenginetofield‐operationalRPMandrecordbelow.
4. Record the time (seconds) it takes for a full stroke for all boom functions.To ensure repeatable
measurements,taketheaverageof3trials.
5. NotallsprayerswillhavethefunctionslistedbelowinFigure3.

Ensuretheboomhassufficienttravelsoitdoesnotcontactthegroundduringthesetests.

Figure3:Pre‐InstallBoomSpeeds


