Page6
Visitwww.solutions.norac.caformoresystem
installationandtroubleshootinginfo.
3.3.1. HydraulicFittingKitDetails(P/N:44865‐03)
Item PartNumber Name Quantity Picture
F04 103839 TADAPTER‐6FJXR6MJT 4

F05 103312 MALEADAPTER‐6MB6MJ 4

F07 104632 TADAPTER‐8FJXR8MJT 1

F08 44928 ORIFICEINSERT.047INONEWAY 2

F09 104369 PLUG‐6MBP 2

F10 104635 TADAPTER‐10FJXR10MJT 1

F11 105003 FEMALETOMALEADAPTER‐10FJ6MJ 1



Notallfittingsareusedforthisinstallation.

Donotusehighspeedpowertools/drillswheninstallinghardware.

TheuseofdielectricgreaseisnotrecommendedonanyNORACelectricalconnections.

Toensureallstainless steelhardwaredoesnotgallorseizeapplyalightcoatingofthe suppliedPermatex
Anti‐seizegreasetoallthreadedpartsuponinstallation.PermatexAnti‐seizelubricantispreferred,butother
similaranti‐seizeproductsmaybeused.

6 M B - 6 M OR X 90
SIZE IN
1/16
TH'S
GENDER: MALE
OR FEMALE
90
° ANGLE
SWIVEL
TYPE
GENDER
SIZE
TYPE:
B - ORB
J - JIC
OR - FLAT
FACE
P - PIPE
Fitting Name
Example:
