Page11
Visitwww.solutions.norac.caformoresystem
installationandtroubleshootinginfo.

Figure7:AccumulatorandNeedleValveLocationonPommierBoom

Figure8:NeedleValveOpened(PommierBoom)

Figure9:AccumulatorOrifice(H05)(PommierBoom)


Startupthesprayerandtestthesprayer’sfunctionality.Unfoldtheboomsandraise/lowereachboomand
themainsection.Ensurethattherearenoleaks.



 
Accumulator
Needle
Valve
