3.4 CHANGING TO AUTOMATIC OR MANUAL MODE
• From the Normal Operating Screen toggle the control panel "AUTO"
switch to change between MANUAL and AUTO modes.
• In MANUAL mode, the boom may be controlled as usual with the
boom control switches on the sprayer’s multifunction handgrip.
• Operating the sprayer’s boom control switches while in AUTO mode
immediately causes the boom to revert to MANUAL mode.
• The sprayer’s joystick switches override automatic height control on
either the left, right, or both sides
• To return to AUTO mode the "AUTO (YES)" switch must be activated.
• The target average height (Section 3.5) can be adjusted by momentarily
pressing the sprayer’s main lift control switches (main up or main
down).
• Pressing and holding the sprayer’s main up or down switches for more
than two seconds reverts ALL booms (left, right, main and roll) to
MANUAL mode. This is a convenient method for switching to
MANUAL mode when folding for transport
3.5 ADJUSTING THE SETPOINT
The system is in AUTO and can have the
target average height (setpoint) adjusted.
• Use the " +/- " switch in AUTO mode to adjust the target height setting.
• Alternately, adjust the main boom target height by momentarily pressing
the sprayer’s main lift control switch while in AUTO mode.
• Each press of the up/down switch increases/decreases the target height
by one selected unit (cm or inches), respectively
• The smallest target height setting is called the minimum height override.
• Default minimum height settings are factory programmed before
shipping.
