5.3. ValveBlockMounting
1. AsuitablemountinglocationforthevalveblockisillustratedinFigure6.
2. Insertthethreadedrodintotheblockanduseahex nuttohold therod.Theblockholesare3/8”(9.5
mm) NC‐1” (25 mm) deep.If bolts are used instead of the threaded
 rod,ensurethebolts threadin at
least3/8”(9.5mm).
3. Usetheremaininghardwaretosecuretheblocktothesprayer.
4. Cutoffexcessthreadedrod,ifnecessary.

Figure6:ValveBlockMounting
