5.4. WingRollCylinderMounting
1. Installthewingrollcylindermountingbracket(B07)onthe boomframe.Clampbrackettoboomframe
usingsuppliedhardware.Tightenhardwareto30‐40ft‐lb(41‐54Nm).
2. Mountthewingrollcylinder(H20)tothebracketusingthesupplied12mmx100mmbolts,flatwashers
and
lockwashers.Installthewingrollcylinderwiththecableendpointingtowardsthe right‐handwing
(whenlookingfromtherearofthesprayer).Tightenmountingboltsto60‐70ft‐lb(81‐95Nm).
3. Routethewingrollcylindercabletothe8‐waycoupler(E11).


Figure7:WingRollCylinderInstalledontheBoomFrame
 
