Page19
Visitwww.solutions.norac.caformoresystem
installationandtroubleshootinginfo.
Ensure the cable is clearof moving parts and will not be damaged during folding.The Ultrasonic MAX
sensors(E07)aretallerthantheUltrasonicsensors(E05).
4. ConnectcablesC05tothe8‐waycouplerandroutealongtheboomtotheouterwingsensors.
5. At the sensor brackets, attach a 2‐way coupler with terminator (E20) to the sprayer boom.The 2‐way
coupler with terminator is the white 2‐way coupler.Plug the sensor and the CANbus cable into the
terminator.
  
Figure16:BracketMountingExample

Figure17:WingBracketMounting
 
Front
