The table below shows what selections are required to log specific data types to raw files in case
there is no acquisition software subscription. Please note that the View Backscatter selection has
no impact on recorded data types, whereas the View WC selection does.
Note also that beam intensity values, at the bottom detection point, are recorded within the
bathymetry packets. This is automatically output and requires no configuration in the GUI. It can be
used to provide coarse backscatter, separately from the side scan and snippets outputs.
Backscatter
Mode Selection
View WC Checkbox
Recorded Data Types in WBM file
7k Records in
s7k file
None
☐
✓ Bathymetry
✗ Compressed Water Column
✗ Side scan
✗ Snippets
✓ 7027
✗ 7042
✗ 7007
✗ 7028
None
☑
✓ Bathymetry
✓ Compressed Water Column
✗ Side scan
✗ Snippets
✓ 7027
✓ 7042
✗ 7007
✗ 7028
Side scan
☑
✓ Bathymetry
✓ Compressed Water Column
✓ Side scan
✗ Snippets
✓ 7027
✓ 7042
✓ 7007
✗ 7028
Snippets/scan
☑
✓ Bathymetry
✓ Compressed Water Column
✓ Side scan
✓ Snippets
✓ 7027
✓ 7042
✓ 7007
✓ 7028
Data Output via Network Subscription
Currently the NORBIT GUI supports streaming s7k records 7000, 7004, 7006, 7007, 7027,
7028, and 7042 via the subscription model (record 7500 with ID 1051). All subscriptions can be
ended with record 7500, ID 1052.
Supported single request records (via record 7500 with ID 1050): 7001
Successful requests are replied with record 7501 (ACK) while unsuccessful ones return record 7502
(NACK). This is based on RESON’s data format definition (DFD) version 2.43. The following table
describes the current s7k records output by the Proxy Server contained in the NORBIT GUI:
Record
Description
7000
Sonar settings
7004
Beam Geometry
7006
Bottom detection results (obsolete bathymetric data)
7007
Side scan data
7027
Bathymetry data (including beam intensity values for coarse backscatter)
7028
Snippets data
7042
Compressed water column data
7500
7k remote control with ID 1051
7501
7k remote control acknowledge
7502
7k remote control not acknowledge
