1.3 Scope of delivery
Pos: 32 /A nl eitu nge n/El ek tro nik/FU u nd S tart er/ 1. Allg emei n es/Si ch erhei ts- und Inst all ati onshi n weis e u nd War n- Gef ahren hin weis e/ne u/W arn- und Gef ahr enhin wei se/ ACH TUN G - D efe kt am G erä t ( durc h Zub ehör ) @ 19 \mod_1511271363545_388.docx @ 2372025 @ @ 1
NOTICE
Defect in the device
Use of unapproved accessories and options (e.g. options from other device series (SK CSX-0)) may result in
defects of the interconnected components.
Only use options and accessories which are explicitly intended for use with this device and are stated accordingly
in this manual.
Pos: 33 /Anleitungen/Elektronik/FU und Starter/1. Allgemeines/Lieferumfang_02 [BU 0135, 0180, 0200] @ 19\mod_1511270930251_388.docx @ 2371989 @ @ 1
Standard version: • IP55 version of device (optionally IP66)
• Operating instructions as PDF file on CD ROM including NORD CON, (PC
parametrisation software)
Pos: 34.1 /A nlei tung en/ Ele ktr oni k/FU und St art er/ 1. Al lge mei nes/ Lief er umfa ng/ Lief eru mfa ng Z ube hör [SK 1xxE, SK 2 xxE] @ 6 \mod_1430913739531_388.docx @ 215564 @ @ 1
Available accessories:
Designation Example Description
Pos: 34.2 /A nlei tung en/ Ele ktr oni k/FU und St art er/ 1. Al lge mei nes/ Lief er umfa ng/ Lief eru mfa ng Z ub ehör _01 _B edien ung [S K 1 x0E, SK 2xxE] @ 6\mod_1430914462320_388.docx @ 215638 @ @ 1
Control and parametrisation options
Parametrisation units for
temporary connection to the
device, handheld
For commissioning, parametrisation and control
of the device.
Model SK PAR-3H, SK CSX-3H
 Section
3.1.1 "Control and Parametrisation
Boxes / Software"
Hand-held control units
For controlling the device,
Model SK POT- …
 Section 3.1.1 "Control and Parametrisation
Boxes / Software"
NORD CON
MS Windows ® - based
software
For commissioning, parametrisation and control
of the device.
Refer to www.nord.com
NORD CON
(Free download)
Pos: 34 .3 /Anl eitu nge n/ Elek tro nik/F U u nd S tart er/ 1. Allg emei n es/ Liefer um fang /Li efer um fang Z ube hör_0 2_B us [BU 018 0, 0 200] @ 6\mod_1430914470232_388.docx @ 215670 @ @ 1
Bus interface
Internal bus interfaces
Customer unit for installation device for:
CANopen, DeviceNet, EtherCAT, Ethernet/IP,
Powerlink, Profibus DP, Profinet IO
Model SK CU4- …
 Section
3.2.1 "Internal customer interfaces
SK CU4-… (installation of modules)"
External bus interfaces
Technology unit for attaching to the device or
alternatively for wall mounting (wall mounting kit
required) for: CANopen, DeviceNet, EtherCAT,
Ethernet/IP, Powerlink, Profibus DP, Profinet IO,
Model SK TU4- …
 Section
3.2.2 "External technology units
SK TU4-… (module attachment)"
