2.6 Operation in potentially explosive environments
Pos: 17 2.2 /A nleitu ngen/ Elektr onik /FU und St art er/1. Al lgemei nes/ Sich erheits - und Ins tall ations hinw eise un d Warn- Gefahrenhinweise/neu/Warn- und Gefahrenhinweise/ATEX - WARNUNG - Explos ionsg efahr durch Elektri zität [SK 1x xE / SK 2xxE ] @ 19\mod_1511794581356_388.docx @ 2373116 @ @ 1
WARNING
Danger of explosion due to electricity
Electric sparks may ignite an explosive atmosphere.
• Do not open the device in an explosive atmosphere and do not remove any covers (e.g.
diagnostic openings).
• All work on the device must only be carried out with the power to the system switched
off.
• Wait for the required time (≥ 30 min) after switching off.
• Before starting work, check that all relevant components (voltage source, connection
cables, connection terminals of the device) are free of voltage using suitable measuring
equipment.
Pos: 17 2.3 /A nleitu ngen/ Elektr onik /FU und St art er/1. Al lgemei nes/ Sich erheits - und Ins tall ations hinw eise un d Warn- Gefahrenhinweise/neu/Warn- und Gefahrenhinweise/ATEX - WARNUNG - Explos ionsg efahr durch hohe Te mperat uren [ SK 1xxE , SK 2xxE] @ 19\mod_1511795266700_388.docx @ 2373256 @ @ 1
WARNING
Explosion hazard due to high temperatures
High temperatures may cause the ignition of an explosive atmosphere.
Temperatures may occur within the device and the motor, which are higher than the maximum
permissible surface temperature of the housing. Dust deposits may restrict the cooling of the
device.
• Clean the device at regular intervals to prevent the accumulation of impermissible dust
deposits.
• Do not open or remove the device from the motor in an explosive atmosphere.
Pos: 17 2.4 /A nleitu ngen/ Elektr onik /FU und St art er/1. Al lgemei nes/ Sich erheits - und Ins tall ations hinw eise un d Warn- Gefahrenhinweise/neu/Warn- und Gefahrenhinweise/ATEX - WARNUNG - E xplos ions g efahr d urch el ektr ost atisc he Aufl ad ung [SK 2x xE] @ 1 9\mod_1511796397243_388.docx @ 2373326 @ @ 1
WARNING
Explosion hazard due to electrostatic charge
Electrostatic charges may cause sudden discharges with the formation of sparks. Sparks may
ignite an explosive atmosphere.
The housing cover is made of plastic. This may become electrostatically charged, e.g. due to
a flow of particles caused by the fan.
• Avoid air movement or air flows at the operation location of the device.
Pos: 172. 5 / Anlei tu ngen /El ektr oni k/F U un d St art er/ 2. M ont age un d Ins tal lati on/ ATE X un d E AC E X ( SK 1 xxE, S K 20 0E) /!Betr i eb i n explosionsgefährdeter Umgebung (ATEX, EAC Ex)_02 [SK 1xxE / SK 2xxE] @ 22\mod_1528892240901_388.docx @ 2426570 @ @ 1
With appropriate modification, the device can be used in certain potentially explosive areas.
If the device is connected to a motor and a gear unit, the EX labelling of the motor and the gear unit
must also be observed. Otherwise the drive must not be operated.
Pos: 17 2.6 /A nleitu ngen/ Elektr onik /FU und St art er/2. M ontage und Inst allati on/AT EX und E AC EX (SK 1 xxE, SK 200E) /Info k ein ATEX SK 2xxE BG IV @ 4\mod_1396435043408_388.docx @ 123522 @ @ 1
Information
SK 2xxE, size 4
Devices of size 4 (SK 2x0E-551-323 … -112-323 and SK 2x0E-112-340 … -222-340) are not approved for
operation in potentially explosive environments.
