Type IP55 IP66 Designation Part Number Document
Power supply 24V / 1~ 230V
X
SK TU4-24V-123-B
275 281 108
TI 275281108
X
SK TU4-24V-123-B-C
275 281 158
TI 275281158
Power supply 24V / 1~ 400V
X
SK TU4-24V-140-B
275 281 109
TI 275281109
X
SK TU4-24V-140-B-C
275 281 159
TI 275281159
PotentiometerBox 1~ 230V X SK TU4-POT-123-B 275 281 110 TI 275281110
X
SK TU4-POT-123-B-C
275 281 160
TI 275281160
PotentiometerBox 1~ 400V
X
SK TU4-POT-140-B
275 281 111
TI 275281111
X
SK TU4-POT-140-B-C
275 281 161
TI 275281161
Required accessories (each module must have an associated connection unit)
Connection unit X SK TI4-TU-NET 275 280 100 TI 275280100
X
SK TI4-TU-NET-C
275 280 600
TI 275280600
Optional accessories
Wall-mounting kit
X
X
SK TIE4-WMK-TU
275 274 002
TI 275274002
Table 10: external modules with power supply SK TU4-24V- … / SK TU4-POT- …
Pos: 20 2 /Anlei tung en/El ektr onik/FU und Star ter/3 . Anzei ge, Be dienu ng und Op tione n/Op tionen [ SK 1xx E, SK 2xxE ]/Ext erne T echnologieboxen SK TU4 …_04 (MSW) [SK 1xxE, SK 2xxE] @ 4\mod_1395134950301_388.docx @ 122266 @ @ 1
Type IP55 IP66 Designation Part Number Document
Maintenance switch
X
SK TU4-MSW
275 281 123
TI 275281123
X SK TU4-MSW-C 275 281 173 TI 275281173
X
SK TU4-MSW-RG
275 281 125
TI 275281125
X
SK TU4-MSW-RG-C
275 281 175
TI 275281175
Required accessories (each module must have a matching connection unit)
Connection unit
X
SK TI4-TU-MSW
275 280 200
TI 275280200
X SK TI4-TU-MSW-C 275 280 700 TI 275280700
Optional accessories
Wall-mounting kit
X
X
SK TIE4-WMK-TU
275 274 002
TI 275274002
Table 11: external modules – maintenance switch SK TU4-MSW- …
