FUNCTIONS
FINE DETAILS
Side sunshade
Front sunshade, mosquito
net and window
Handlebar
Roll the shade up and place it
under the upper edge of the
side canopy.
Secure it with Velcro.
Front sunshade, mosquito
net and window:
Pull the zip up on both sides.
Roll the part(s) up and place
them in the pocket on top of
the canopy.
Secure it with Velcro.
The handlebar can be
adjusted to any positions
desired by pressing in the
round plastic buttons on each
side of the handlebar and
rotating it in the desired
position.
The safety strap is attached to
the handlebar when it is not in
use.
FOLDING THE CART
1
2
3
4
Set the seat in recumbent
position by detaching the
straps in the seatback.
Open the vertical zips, one on
each side.
Lift the overlapping pieces of
fabric on top of the canopy.
Lift the safety lock (handlebar)
up. Press the release buttons
together.
Push the rear part of the
canopy down and under the
front part of the canopy.
Collapse the handlebar.
Detach bicycle fork and place
it under the seat. Detach
wheels and place them on the
seat.
WARNING
Be careful not to injure your fingers.
ATTENTION
Roll up the window, sunshade and mosquito net to avoid damage.
WARNING
Mind that the axle bolts do not damage the seat or the canopy.
