Nordic Cab EXPLORER - BICYCLE TRAILER

NordicCab Instructions and user manual for the NordicCab Explorer Page 20 of 25
BICYCLE TRAILER
1
2
3
4
Pull the locking pin (a big,
spring loaded locking pin) on
the left side (in the direction of
travel) and insert the bicycle
arm. Release the locking pin
and push the tube in until it
clicks in place.
After the bicycle arm is set in
the correct position, attach the
carbine hook on the safety
cable to the red loop on the
cart.
Detach rear axle bolt from hub
on the bicycle. ATTENTION:
Be careful not to lose any
small parts or springs.
If your bicycle has a thick axle,
the nut must be unfastened.
Place the bicycle attachment
over the axle bolt and attach it
back to the hub exactly as you
detached it. If the axle is thick,
the nut is attached over the
bicycle attachment. NOTE the
bicycle attachment should
stick out from the bicycle.
Insert the tip of the bicycle arm
into the bicycle attachment.
Lock the bicycle attachment
securely to the arm with a U
locking pin.
Thread the safety cable
around the bicycle frame
(behind the fork) and back,
and secure the hook on the
cable. Tighten the cable while
the plastic sleeve on the arm
is placed towards the casing,
and lock the cable by moving
the plastic sleeve towards the
bend on the bicycle arm (DO
NOT USE FORCE)
5
6
A flag must always be used
when using the Explorer as a
bicycle trailer.
Attach the two flagpoles
together, and insert in the
long, narrow pouch on the left
canopy panel.
For better shock
damping, a little lower air
pressure can be used.
