12
10
10. Press the tabs on the Front Upright Cover (20)
into the Rear Upright Cover (21). Then, attach
the Front Upright Cover to the Upright (2) with an
M4 x 16mm Screw (67).
67
20
2
21
9
9. Hold the Rear Upright Cover (21) against the
Upright (2) and against the Console (3). Attach
the Rear Upright Cover to the Upright with five
M4 x 16mm Screws (67); start all the Screws,
and then tighten them.
67
67
21
2
3
