ASSEMBLY
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and re-
move the packing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver and
an adjustable wrench.
As you assemble the exercice bike, use the drawings below to identify small parts. The number in
parentheses below each drawing is the key number of the part, from the PART LIST near the end of
this manual. The number following the parentheses is the quantity needed for assembly.
Note: If a part is not in the hardware kit, check to see if it has been preassembled.
NO 26*2
NO 92*1
NO 83*4
NO 33*6 NO 34*6
NO 29*2 NO 30*2
NO 14*4 NO 16*4
NO 22*6 NO 91*1
NO 39*6 NO 40*6 NO 22*6
NO 13*3
NO 22*3
NO 34*3
NO 19*2
NO 21*2
NO 22*2
NO 23*2
NO 21*2 NO 22*2 NO 23*2
