TABELA DE IDENTIFICAÇÃO DE PEÇAS
Consulte as ilustrações abaixo para identificar pequenas peças utilizadas na montagem. O número entre parên-
tesis junto a cada peça é o número da peça, da LISTA DE PEÇAS perto do fim deste manual. O número a seguir
aos parêntesis é a quantidade necessária para a montagem. Nota: Se uma peça não se encontrar no kit de
equipamento, verifique se foi previamente montada. Pode ser incluído equipamento extra.
Parafuso M4 x 16mm
(92)–6
Parafuso M4 x 28mm
(99)–4
Parafuso M8 x 20mm
(80)–2
Anilha M8
(33)–2
Anilha Fendida M10
(78)–10
Contraporca M8
(77)–4
Parafuso M10 x 95mm (82)–4Parafuso M10 x 48mm (75)–6
Pino de Espera com Plástico
(31)–2
Parafuso M10 x 20mm
(79)–6
Pino M8 x 45mm
(76)–4
