NordicTrack E5vi Elliptical User Manual

9
6
6. Identify the Right Pedal (14), which is marked
with a “Right” sticker, and orient it as shown.
A
ttach the Right Pedal (14) to the Right Pedal
Arm (12) with four M6 x 12mm Patch Screws
(
111) and four M6 Split Washers (112).
Attach the Left Pedal (15) to the Left Pedal
Arm (13) in the same way.
12
14
1
3
15
111
111
112
112
7
8
6
7
9
102
103
103
7. Identify the Right Upper Body Arm (8), which is
marked with a “Right” sticker, and orient it as
shown.
Attach the Right Upper Body Arm (8) to the
Right Upper Body Leg (6) with three M8 x
16mm Patch Screws (102) and three M8 Split
Washers (103).
Attach the Left Upper Body Arm (9) to the Left
Upper Body Leg (7) in the same way.
