NordicTrack GX 4.5 PRO - Assembly - Part 5; Seat Carriage and Seat Knob Installation; Connect Main Wire to Console; Attach Console to Upright

10
10
9. Remove the Seat Knob (26) from the Seat
Bracket (30) inside the Seat Carriage (24).
Next, set the Seat Carriage (24) on the Seat
Post (6). Then, insert the Seat Knob (26) upward
into the Seat Post, and tighten the Seat Knob
into the Seat Bracket (30) inside the Seat
Carriage.
9
26
24
6
13
30
4
10. While a second person holds the Console (13)
near the Upright (4), connect the Main Wire (58)
to the matching wire on the Console.
Insert the excess wire into the Upright (4).
58
34
13
4
Avoid pinching
the wire
11
11. Tip: Avoid pinching the wire. Attach the
Console (13) to the Upright (4) with four
M4 x 18mm Truss Screws (34); start all the
Truss Screws, and then tighten them.
