NordicTrack NTL10224-INT.1 User Manual

11
7
7. Identify the Right Handrail Cover (75). Insert
the front edge of the Right Handrail Cover into
the top of the handrail assembly (G) as shown.
Then, press down on the top of the Right
Handrail Cover until it snaps into place.
Attach the Left Handrail Cover (74) to the
handrail assembly (G) in the same way.
G
74
75
6
6. See the inset drawing. Press the small latch (H)
on the connector on the Upright Wire (82), and
remove the wire pull (B). Discard the wire pull.
Next, connect the Upright Wire (82) to the
Handrail Wire (83). IMPORTANT: Slide the wire
connectors together until they snap into
place with an audible click. You must con-
nect the wires properly for your treadmill to
function properly. Then, insert the connectors
and the excess wire into the Right Upright (85).
85
H
B
82
83
82
85

NordicTrack NTL10224-INT.1 Specifications

General

Brand	NordicTrack
Model	NTL10224-INT.1
Category	Treadmill
Language	English
